Explosion-Proof Valve
Product Overview
Product OverviewThe Explosion-Proof Valve is specially designed to ensure safe, stable, and certified control of gases and liquids in flammable, explosive, or dust-prone environments. It plays a vital role in preventing fire and explosion risks by isolating any potential ignition sources within its fully sealed structure. Manufactured by Vcore Valves, this product is constructed using flameproof-grade materials such as carbon steel and stainless steel and features certified explosion-proof electric or pneumatic actuators. It is widely applied in chemical plants, oil refineries, paint production, grain processing plants, and gas networks—where safe operation is not optional but mandatory.
Key Features:
Certified for hazardous environments (ATEX, IECEx, CNEX); explosion-proof electric or pneumatic actuator with sealed ignition chamber; anti-spark structure and static-proof internal components; full-port design allows reliable flow with minimal pressure drop; high-integrity sealing for zero leakage; long lifecycle and reduced maintenance.
Technical Specifications
| Component | Specification |
|---|---|
| Valve Type | Explosion-Proof Electric / Pneumatic Control Valve |
| Valve Body | WCB Cast Steel, CF8 / CF8M Stainless Steel, Ductile Iron |
| Valve Seat | PTFE / Graphite / Metal-to-Metal Seal |
| Nominal Size | DN25–DN600 (1”–24”) |
| Pressure Rating | PN10–PN100 / 150LB–600LB |
| Temperature Range | -40°C to +300°C |
| Actuator Type | ATEX / IECEx / CNEX Certified Electric or Pneumatic Actuator |
| Protection Grade | Ex d IIB / IIC T4–T6, Ex tD A21 IP65 / IP67 Optional |
| Connection Ends | Flanged (ANSI, DIN, JIS), Threaded, Socket Weld |
| Certification | Explosion-proof standards compliant (ATEX / IECEx / CNEX – upon request) |
Main Dimensions & Weight (mm/kg)
| Size (DN) | Length (L) | Height (H) | Width (W) | Weight (kg) |
|---|---|---|---|---|
| 25 (1″) | 160 | 220 | 120 | 9 |
| 50 (2″) | 203 | 290 | 140 | 15 |
| 80 (3″) | 241 | 340 | 170 | 25 |
| 100 (4″) | 292 | 400 | 200 | 38 |
| 150 (6″) | 356 | 460 | 240 | 60 |
| 200 (8″) | 495 | 580 | 300 | 95 |
| 300 (12″) | 635 | 720 | 380 | 165 |
| 400 (16″) | 762 | 850 | 460 | 230 |
| 600 (24″) | 900 | 1050 | 580 | 320 |
Functions and Advantages
Functions and Advantages-
Flameproof actuator ensures safe valve operation in flammable or explosive atmospheres.
-
Fully enclosed electrical and mechanical components to eliminate ignition risk.
-
Durable construction and precision seal provide leak-free performance under pressure.
-
Explosion-proof grades meet Zone 1 & 2 (gas) and Zone 21 & 22 (dust) environment requirements.
-
Easy installation and low maintenance in critical safety systems.
Application Fields
-
Petrochemical & Refining Plants
-
LNG Terminals & Gas Transmission Systems
-
Battery Manufacturing & Paint Production
-
Dust-Prone Grain Storage & Processing Facilities
-
Chemical Reactors and Blending Units
-
Emergency Shutdown Systems in Hazardous Zones
